Blood Bank Refrigerator B131
Blood Bank Refrigerator with 121 L | 4.27 cu ft gross volume.
- Set Temperature: +4°C
- Climate class (ambient temperature range): +10°C to +32°C
- Alarm limits: +2°C | +6°C
- External dimensions (HxWxD): 830 x 595 x 695 mm | 32.68 x 23.43 x 27.36 in
- Refrigerant Type: Natural R600a
Reliability
- Forced air cooling system for uniform and stable temperature distribution
- Fast temperature recovery even in case of frequent door openings
- Safety thermostat preventing temperature below freezing
- Extended autonomy in case of power failure
- Audio-visual alarm system with remote transmission via SMS or email
- °B Connected universal software for remote monitoring, reporting (in compliance with FDA 21 CFR Part 11), and long-term archiving in combination with a Data Communication Unit
Efficiency
- Natural refrigerant of high cooling efficiency in conformity with US SNAP and EU F-Gas regulations
- Polypropylene cabinets injected with polyurethane foam providing strong thermal insulation
- Sealed gaskets and 4-layer glass window minimizing cold air loss
- Interior automatic LED lighting for lower energy consumption
- One-piece cabinet manufactured with the unique technique of rotational moulding
Convenience
- Smooth cleanable surfaces
- Low-noise appliance
- Low heat emission
- Modular interior equipment
- Organic glass window for better visibility of the refrigerated content
- Easy export of data on USB
- Electronics with easily accessible temperature display
- Gasket heater minimizing condensation
- Lifetime warranty corrosion-free cabinet
| Gross volume | 121 L | 4.27 cu ft |
|---|---|
| Blood bag capacity (450 ml) | 51 |
| Blood bag capacity (350 ml) | 84 |
| Set Temperature | +4°C |
| Alarm limits | +2°C | +6°C |
| Climate class (ambient temperature range) | +10°C to +32°C |
| Certifications | cCSAus | EU MDR Class IIa | ISO 14664-1 | Class 4 | SCoPE | US FDA Class II |
| Cooling technology | Forced air cooling system |
| External dimensions (HxWxD) | 830 x 595 x 695 mm | 32.68 x 23.43 x 27.36 in |
| Internal dimensions (HxWxD) | 630 x 475 x 470 mm | 24.80 x 18.70 x 18.50 in |
| Net weight | 59 kg | 130.07 lb |
| Frequency | 50-60 Hz |
| Supply voltage | 220-240V |
| Energy consumption | 1.1 kWh/24h |
| Noise level | 35 dB (50 Hz) | 36 dB (60 Hz) |
| Refrigerant Type | Natural R600a |
| Heat emission | 39 Kcal/h |
| Materials | Polypropylene/aluminum |
| Display | Digital display |
| Remote monitoring | Optional °B Connected software via data communication unit |
| Hold over time | 1.7 h (+4°C to +10°C) |
| Defrosting technique | Natural |
| Access control | Lock with 2 keys |
| Data export | USB port |
| Product Type | Blood Bank Refrigerator |
