Vaccine Refrigerator & Ice-pack Freezer TCW2000AC
Vaccine Refrigerator & Ice-pack Freezer
- Set Temperature: +5°C (R) | -20°C (F)
- Vaccine storage capacity: 60 L
- Ice-pack storage (at 0.6 L): 20
- Certifications: EMC directive 2014/30/EC | Low voltage 2014/35/EUC
- Freeze protection level: Grade A
- Climate class (ambient temperature range): Hot zone (+43°C)
- Energy source: AC
Innovative technology
- Equipped with 1 voltage protector
- Door gasket easily replaceable and washable
- External temperature display and real-time visualization on the web
Resistance to harsh environment
- Designed to operate in tropical conditions
- Rotomoulded body construction: rust free and extremely robust
- Humidity control: no condensation issues in the fridge
Safety and traceability
- Strong insulation
- Silicone gaskets and lockable clasps: tight closing and restricted access
- Audio-visual alarm system with remote transmission
- Remote temperature monitoring solution, comprising a data logger and a digital platform
| Vaccine storage capacity | 60 L |
|---|---|
| Ice-pack storage (at 0.6 L) | 20 |
| Refrigerator gross volume | 118 L | 4.17 cu ft |
| Freezer gross volume | 42 L | 1.48 cu ft |
| Set Temperature | +5°C (R) | -20°C (F) |
| Climate class (ambient temperature range) | Hot zone (+43°C) |
| Certifications | EMC directive 2014/30/EC | Low voltage 2014/35/EUC |
| External dimensions (HxWxD) | 910 x 1270 x 780 mm | 35.83 x 50.00 x 30.71 in |
| Net weight | 107 kg | 235.89 lb |
| Shipping weight | 131 kg |
| Frequency | 50-60 Hz |
| Supply voltage | 220-240V |
| Refrigerant type | R134a |
| Materials | Polyethylene |
| Cool down | 9.6h |
| Hold over time | 39h24 min at +43°C |
| Energy consumption /24h (stable running) | 1.87kWh/24h at 43°C |
| Energy source | AC |
| Freeze protection level | Grade A |
| Product type | Vaccine Refrigerator & Ice-pack Freezer |
