Multimode: Vaccine Refrigerator or Vaccine/Ice-pack Freezer TCW3000AC

Multimode: Vaccine Refrigerator or Vaccine/Ice-pack Freezer with 204 L | 7.2 cu ft gross volume.

  • Set Temperature: +5°C (R) | -20°C (F)
  • Vaccine storage capacity: 150 L
  • WHO PQS Code : E003/017
  • Freeze protection: Grade A
  • Climate class (ambient temperature range): Hot zone (+43°C)
  • Energy source: AC

Innovative technology

  • Able to be set as either a vaccine refrigerator, a vaccine freezer or an ice-pack freezer
  • Able to meet different temperature ranges: -20°C to 0°C or +2°C to +8°C
  • Equipped with 1 voltage protector
  • Door gasket easily replaceable and washable
  • External temperature display and real-time visualization on the web

Resistance to harsh environment

  • Designed to operate in tropical conditions
  • Rotomoulded body construction: rust free and extremely robust
  • Humidity control: no condensation issues in the fridge

Safety and traceability

  • Strong insulation
  • Silicone gaskets and lockable claps: tight closing and restricted access
  • Audio-visual alarm system with remote transmission
  • Remote temperature monitoring solution, comprising a data logger and a digital platform
Gross volume

204 L | 7.2 cu ft

Vaccine storage capacity

150 L

Set Temperature

+5°C (R) | -20°C (F)

Climate class (ambient temperature range)

Hot zone (+43°C)


EMC directive 2014/30/EC | Low voltage 2014/35/EC | WHO PQS E003/017

External dimensions (HxWxD)

910 x 1270 x 780 mm | 35.83 x 50.00 x 30.71 in

Net weight

105 kg | 231.49 lb

Shipping weight

123 kg


50-60 Hz

Supply voltage


Refrigerant Type




Hold over time

3h55 min at 43°C (F) | 53h10 min at 43°C (R)

Energy cons. 24h stable

1.37kWH/24h at 43°C (R ) | 3.83 kWH/24h at 43°C (F )

Energy source


Freeze protection

Grade A



Product Type

Multimode: Vaccine Refrigerator or Vaccine/Ice-pack Freezer
